GAG
Wintech Korea’s GAG sheets have color expression and sheen that can be adjusted to customer requirements, maximizing product values and providing greater consumer satisfaction.
Characteristics
- Eco-friendliness
- Various patterns and colors available including high gloss and matte surfaces
- UV-blocking
- Scratch-resistant
- Excellent weather-proof and chemical-resistant qualities
Production specifications
Thickness: 0.25–1.5 mm (10–59 mil)
Width: Max. 1,350 mm (53”)
Material: Can be cut according to customer requests in rolls or flat sheets
Width: Max. 1,350 mm (53”)
Material: Can be cut according to customer requests in rolls or flat sheets
Applicable areas
Surface material for kitchens, housing, office furniture
Product info (thickness: 0.25–1.00 mm)
| Property | Unit | Search filters | Test method |
|---|---|---|---|
| Specific gravity | - | 1.34 | |
| Thickness | mm | Target ± 5% | WTX Method |
| Width | mm | Target ± 0~3 | WTX Method |
| Length | mm | Target ± 0~3 | WTX Method |
| Squareness | mm | L1-L2≤3.0 | WTX Method |
| Haze | % | Below 5.0 | JIS K 7105 |
| Transmittance | % | Above 88.0 | JIS K 7105 |
| Softening temperature | ℃ | 78 | DSC |
| Softening point | ℃ | 76 | ASTM D1525 |
| Tensile strength | ㎫ | 57.0 | ASTM D638 |
| Tensile factor | ㎬ | 2.75 | ASTM D638 |
| Elongation rate | % | 388 | ASTM D638 |
